ASG Series: Asynchronous Low Voltage AC Alternators | IP54 Single-Phase 2-poles

Product Overview

The Sincro ASG series features premium asynchronous low voltage AC alternators built for constant speed applications. Operating as 2-pole, single-phase machines at 3000/3600 RPM, they are usually coupled to engines to create highly dependable portable generating sets. Engineered with advanced induction technology, these alternators deliver exceptional durability for both standard and customized executions.

Key Features & Benefits

• Advanced Induction Technology: Operates as a highly efficient brushless asynchronous alternator. Capacitors for self-excitation are included as standard.

• Superior Power Quality: They offer an excellent wave form with low THD values. This makes them ideal to supply electricity to resistive loads and electronic devices safely.

• Rugged IP54 Enclosure: They use a die-cast aluminium housing. This is designed to guarantee IP54 protection and features an IC411 cooling system (TEFC).

• Maintenance-Free Reliability: These generators are very reliable and robust. Because no brushes are needed, routine maintenance is kept to an absolute minimum.

• Flexible Coupling Options: Standard couplings include SAE J609a-J609b across frame sizes 80-90, 112, and 132, as well as cone options. Different couplings are available on request.

• Customizable Executions: Beyond the standard IP54 build, drip-proof construction (IP23) is available on request. Single-phase versions with sockets (IP44) are also available.

Ideal Applications

Thanks to their robust, maintenance-free design and high power quality, the ASG series single-phase alternators are perfectly suited for:

• Portable Generating Sets: These generators are usually coupled to engines to create reliable, easily transportable generating sets.

• Resistive Loads: Their excellent wave form makes them ideal to supply electricity to various resistive loads.

• Electronic Devices: They deliver clean, stable power that is highly suitable for safely running sensitive electronic devices.

Single-Phase Performance Range

The ASG single-phase alternators ($pf=1$) deliver reliable power across a variety of models at 230V / 50Hz:

• ASG 80C2-M: 1.2 kVA

• ASG 80D2-M: 1.6 kVA

• ASG 90SA2-M: 2.0 kVA

• ASG 90SB2-M: 2.2 kVA

• ASG 112MB2-M: 3.5 kVA

Note: Ratings are based on standard operating conditions, including an ambient temperature of 40°C and an altitude below 1000 m. a.s.l.
