PMM 112MC/12-4 Permanent Magnets Motor Synchronous 3Phase/ 12Poles/ 4Modules

SOGA PMM 112MC/12-4 Synchronous Brushless Permanent Magnet Motor

3 Phase/ 12 Poles/ 4 Modules

The SOGA PMM 112MC/12-4 represents the ultimate performance level in SOGA’s innovative PMM series, delivering exceptional power and torque in a compact frame. This premium three-phase synchronous permanent magnet motor features an advanced neodymium (NdFeb) modular multipole rotor with 12 poles and 4 modules – the highest configuration available in the 112mm frame size – making it the pinnacle choice for applications demanding maximum performance.

Compatible with most standard inverters commonly used with asynchronous motors (provided they support synchronous permanent magnet motors), the PMM 112MC/12-4 offers unparalleled efficiency and torque density for the most demanding industrial applications.

Key Features

• State-of-the-art synchronous permanent magnet technology

• Premium-grade neodymium (NdFeb) modular multipole rotor

• Maximum-performance 12-pole, 4-module configuration

• Highest power and torque density in the 112mm frame class

• Enhanced thermal performance for sustained high-output operation

• Compatible with standard inverters

• Versatile performance across three specialized operating ranges

• Superior efficiency and exceptional torque characteristics

• Heavy-duty industrial construction for extreme application environments

Versatile Operating Ranges

1. Low Speed Range

Delivers extraordinary torque at lower rotational speeds, making it the optimal solution for:

• High-torque gearboxes

• Industrial winches

• Heavy-duty motorized roller conveyors

• Industrial fans

• High-capacity compressors

• Industrial mixers

• Advanced automation systems requiring maximum torque

2. High Efficiency Range

Engineered for ultimate energy efficiency while delivering superior power output in demanding applications such as:

• Commercial and industrial HVAC systems

• Heavy-duty material handling equipment

• Industrial vacuum pumps

• High-performance screw compressors

3. Constant Torque Range

Designed to maintain consistent high torque across an extensive speed range, perfect for advanced automation applications including:

• High-capacity roller conveyors

• Industrial-grade conveyor belts

• Commercial unwinder machines

• High-volume feeders

• Industrial presses

• Heavy-duty gearboxes

Benefits

• Ultimate Torque Density: Quad-module design provides the highest torque output possible in this frame size

• Maximum Power Output: Significantly greater power capacity compared to all other PMM 112 variants

• Industry-Leading Energy Efficiency: Superior efficiency metrics across all operating ranges

• Precision Control Performance: Exceptional dynamic response and positioning accuracy for mission-critical applications

• Comprehensive Versatility: Three distinct performance profiles in one premium motor design

• Superior Reliability: Engineered for extended service life in the most challenging industrial environments

• Simplified System Integration: Compatible with standard inverters despite its advanced capabilities

• Reduced Total Cost of Ownership: Lower energy consumption and maintenance requirements compared to conventional alternatives

Applications

The PMM 112MC/12-4 with its premium quad-module, 12-pole configuration is specifically engineered for:

• High-Performance Industrial Systems: Ideal for applications requiring the absolute maximum power and torque in a 112mm frame

• Replacement for Larger Conventional Motors: Can replace significantly larger traditional motors while delivering equal or superior performance

• Critical Energy-Efficiency Applications: Perfect for systems where energy efficiency directly impacts operational costs

• Precision Manufacturing Equipment: Delivers the ultimate responsiveness and control needed for high-precision production equipment

• Heavy-Duty Material Transport: Provides exceptional torque and reliability for the most demanding conveyor and transport systems

• Continuous Heavy-Load Operations: Engineered for reliable performance in 24/7 operational environments under sustained high loads

• Variable Speed High-Torque Applications: Maintains optimal efficiency and torque across an extensive operating speed range

For detailed technical specifications, customization options, or to discuss how the SOGA PMM 112MC/12-4 can meet your most demanding professional application requirements, please contact our sales team.
